| Sensor | Super 35mm CMOS |
| Total Pixels | Approx. 9.84MP (4206 x 2340) |
| Effective Pixels | Approx. 8.29MP (3840 x 2160) |
| Resolution | 1920 x 1080, 1280 x 720 |
| Min. Sub. Illum. | 0.015lux or less (at 56dB, F1.2, 29.97P, 1/30sec. shutter) |
| Color Filter Array | RGB Bayer |
| Lens System | |
| Canon EF Mount | Cinema Lock type |
| Cinema Lock type | Select EF, EF-S and Cinema (EF-mount) Lenses |
| Input Terminals | |
| GEN LOCK | Black burst or Tri-level reference |
| Microphone | φ3.5mm stereo mini jack (plug-in power mic supported) |
| Remote Control | Remote A: φ2.5mm stereo mini jack (Canon protocol)
Remote B: Circular 8-pin for RS-422 (Canon protocol) |
| Output Terminals | |
| 3G / HD-SDI | Terminal 1 (On screen display optional)
Terminal 2 (Clean out only)
Bit Depth: YCbCr422 10bits (effective bits: 8) |
Frame Rates:
1920 x 1080: 59.94P / 59.94i / 50P / 50i / 29.97P / 25P / 23.98P
1280 x 720: 59.94P / 50P / 29.97P / 25P / 23.98P
*Cannot set framerate and output size separately by SDI and HDMI. |
| HDMI | Terminal 1 (On screen display optional)
Bit Depth: RGB444, YCbCr422, YCbCr444 (effective bits: 8 for each format) |
Frame Rates:
1920 x 1080: 59.94P / 59.94i / 50P / 50i / 29.97P / 25P / 23.98P
1280 x 720: 59.94P / 50P / 29.97P / 25P / 23.98P
*Cannot set framerate and output size separately by SDI and HDMI.
**640 x 480: 59.94P & 768 x 576: 50P will be output when connected with a monitor that support 480P and 576P inputs. Cannot be set from the menu and the on screen display will not show. |
| Exposure Modes | |
| Auto Exposure (AE) | Iris, Gain, Shutter and ND filter operating together (Cannot set auto / manual separately) |
| AE shift/AE response selectable |
| AGC limit can be set from 30dB to 54dB (3dB intervals) / Off (56dB) |
| Manual | Iris: | 1/2 stops (push auto iris can be set to an assign button) |
| Gain: | 0dB to 56dB @ 3dB intervals (approx. ISO 204,800 equivalent at 56dB)
Shutter: 1/3 to 1/2000 (1/4 stops); 1/3 only at 23.98p |
| Image Control | |
| Focus Control | Continuos Auto-Focus (Dual Pixel CMOS AF)
One-Shot AF (can be set to an assign button) |
| W/B | AWB (2,000K-15,000K), Daylight, Tungsten, Custom Set A, Custom Set B |
| Optical Filters | ND filters: | 1/8 & 1/64 Built-in (auto or motorized manual) |
| IR cut filter: | On/Off (motorized manual) |
| Digital Teleconverter | 2x, 4x, 8x |
| Custom Picture Setting | EOS Standard, Wide DR, Canon Log, Custom 1-6 |
| Other Functions | Auto black balance, color bar, test tone (interlocking with color bar), assign buttons, peripheral illumination correction, focus limit, crop for EF-S Lens, scan reverse, flicker reduction, noise reduction, time display, hour meter |
| Power Input | |
| Terminals | XLR 4-pin or terminal block 2-pin jack |
| Input | DC +11V ~ +17V |
| Consumption | Power Consumption Approx. 11W (body only) |
| Other | |
| Operating Temperature | Approx. 0 - 40°C (32 - 104°F) |
| Dimensions | 4.0 x 4.6 x 4.4in. (102 x 116 x 113mm) |
| Weight | Approx. 2.2lbs. (1,100g) |
| Included in the Box | ME200S-SH, 2-pin DC Power Contact |
| Related Accessories | Canon RC-V100 Remote Controller, Canon EF Lenses |
