Description |
High production wide format monochrome print, copy and scan system |
|
Technology |
LED - Océ Copy Press |
|
Speed |
6, 8 or 10 A0/min. |
|
Warm-up Time |
17 minutes (from cold start-up) |
|
Configuration |
Printer, multifunction with 1 printer and choice of 2 scanners |
|
Roll Options |
2 - 6 rolls |
|
Output Delivery |
Integrated receiving tray - front |
|
Certifications |
ENERGY STAR@, TuV GS, CETECOM, CE, UL, Complies with
Directive 89 / 336 / EEC and FCC rules and regulations, part 15 Class A |
Printer
|
|
|
Print Resolution |
True 400 x 400dpi |
|
Paper Capacity |
Up to 200m per roll, max. 6 rolls |
|
Output Sizes Width |
296 - 914mm |
|
Output Sizes Length |
297mm - 15m |
|
Paper Weight |
75 -100g/m2 |
|
Media Type |
Plain, transparent, recycled, fluorescent, coloured papers, films and vellums |
|
|
|
|
Controller Type |
Power Logic Controller with embedded Windows XP |
|
Memory |
Standard 2GB |
|
Hard Drive |
2 x 250GB |
|
Page Description Language |
HPGL, HPGL2, CalComp, TIFF, CALS-I
Adobe PostScript 3 / PDF (optional) |
|
|
|
|
Scanner Type + Technology |
B&W scanner - CCD with Océ Image Logic |
|
Scan Resolution |
400dpi |
|
Scan Speed |
10m/min. |
|
Scan Format |
TIFF (uncompressed, Packbits, G3, G4 and LZW), PDF (uncompressed, Flate LZW, and G4), CALS, JPEG |
|
Scan Destination |
FTP, Network Directory, Controller |
|
Original Size Width / Length |
210 -912mm / 210mm - 15m |
|
Original Thickness |
3mm (basic configuration), 15mm (thick original configuration) |
|
Scaling |
25 - 400% |
|
Preset Modes |
Lines & text, photo, greys & lines, dark original, blueprint
Auto mode with Océ Image Logic |
Print, Copy and Scan Workflow
|
|
|
General Workflow |
Concurrent print, copy, scan and file processing |
|
Submission |
Océ Print Exec Workgroup |
|
Job Management |
Print and history queue, inbox, manage queue, secure user rights management
Océ Remote Logic® for remote job management |
|
Accounting |
Océ Account Center |
|
Templates |
5 copy & scan templates, unlimited print templates |
Options
|
|
|
Hardware Options |
Folder, stacker and Océ Image Logic scanner - separate |
|
Software Options |
Adobe Postscript 3 / PDF
Océ Repro Desk, Océ Viewstation |
|
|
|
|
Client Operating System Support |
Windows XP / Vista / server2003 / Terminal Server / Citrix Metaframe (WPD)
MAC OS9 / X (Adobe PS3 driver) |
|
Standard Interface |
10 / 100 BaseT with RJ4 |
|
Network Protocols |
TCP/IP, SMB (for scan-to-file only), IPX/SPX, FTP, LPD |
Additional Information
|
|
|
Power Consumption Active Mode (printing) |
4100W |
|
Power Consumption Ready Mode (standby) |
820W |
|
Power Consumption Sleep Mode |
13W |
|
Power Requirements (V / Hz / Ams) |
100 - 120V, 200 - 240V, 50 / 60Hz, 16A |
|
Noise Level (Active / Ready) |
59dB (A) / 46dB (A) |
|
Size Print Engine (H x W x D) |
140 x 172 x 114,6cm |
|
Weight Print Engine |
939kg |
|
Size Scanner (H x W x D) |
123,5 x 132 x 64cm |
|
Weight Scanner |
166kg |
Supplies
|
|
|
Consumable Type |
Monocomponent E1 Toner |
|
Size / Yield |
Toner bottle size: |
2 x 800g |
