Printer | |
Machine Type | UV flatbed printer |
Image Technology | - Piezoelectric inkjet using Océ VariaDot® Imaging Technology
- 636 piezoelectric nozzles per colour
|
Resolution | Near-photographic image quality, perfect text as small as 2-pt in size |
System Design | |
Flatbed | True flatbed architecture for printing to rigid media or objects |
Roll media | Roll Media Option for flexible media |
Ink System | |
Colours | - UV curable inks in quick-exchange ink bags
- Black, Cyan, Magenta, Yellow in two liter bags
- White ink and Varnish in one litre bags
|
Print Speed | |
Print Speed | | Flatbed (m2/hr) | Roll Media Option (m2/hr) |
Express mode | 32.8 | 25.6 |
Production mode | 20.3 | 16.9 |
Quality mode | 14.0 | 11.6 |
Fine Art mode | 11.3 | 9.4 |
High Definition mode | 5.9 | 5.2 |
White Ink, 2-layer | 7.0 | 5.8 |
Media | |
Rigid Media Size | 1.25m x 2.5m x 50.8mm thick |
Rigid Media Printing Width | 1.26m x 2.51m, edge-to-edge printing (full bleed) |
Roll Media Width | 0.9m to 2.2m wide |
Roll Media Printing Width | 2.19m max. |
Media Assortment | Canon provides a complete assortment of roll-based media including self-adhesive vinyl, banner and textiles, as well as various indoor and outdoor paper products |
Media Handling | Flatbed and Roll Media Option operate independently; no conversion required between media types |
Image Processing and Connectivity | |
Image Processing | ONYX® ThriveTM print workflow software Océ Edition |
Connectivity | 10 / 100 / 1000Base-T Ethernet |
Operational Environment and Dimensions | |
Electrical | - 2 x 50Hz, 200 - 240VAC, single phase, 16A
- 2 x 60Hz, 200 - 240VAC, single phase, 20A
|
Operating Environment | - Temperature: 18°C to 30°C
- RH: 30% - 70%, non-condensing
|
Physical | - Printer only: 4.66m x 2.0m; 475kg, uncrated
- Printer + Roll Media Option: 4.66m x 2.3m; 650kg, uncrated
|
Other | |
Service & Support | Canon offers several contract options tuned to individual customer needs, to ensure the highest printer uptime, enabling our customers to achieve their business goals. |
