Printer
|
|
|
Machine Type |
UV flatbed printer |
|
Image Technology |
-
Piezoelectric inkjet using Océ VariaDot® Imaging Technology
-
636 piezoelectric nozzles per colour
|
|
Resolution |
Near-photographic image quality, perfect text as small as 2-pt in size |
System Design
|
|
|
Flatbed |
-
True flatbed architecture for printing to rigid media or objects
|
|
Roll media |
-
Roll Media Option for flexible media
|
Ink System
|
|
|
Colours |
-
UV curable inks in quick-exchange ink bags
-
Black, Cyan, Magenta, Yellow in two liter bags
|
Print Speed
|
|
|
Print Speed |
|
Flatbed
(m2/hr) |
Roll Media Option (m2/hr) |
|
Express mode |
34.2 |
25.6 |
|
Production mode |
21.0 |
16.9 |
|
Quality mode |
14.4 |
11.6 |
|
Fine Art mode |
11.7 |
9.4 |
|
High Definition mode |
6.1 |
5.2 |
Media
|
|
|
Rigid Media Size |
2.5m x 3.05m x 50.8mm thick |
|
Rigid Media Printing Width |
2.51m x 3.06m, edge-to-edge printing (full bleed) |
|
Roll Media Width |
0.9m to 2.2m wide |
|
Roll Media Printing Width |
2.19m max. |
|
Media Assortment |
Canon provides a complete assortment of roll-based media including self-adhesive vinyl, banner and textiles, as well as various indoor and outdoor paper products |
|
Media Handling |
Flatbed and Roll Media Option operate independently; no conversion required between media types |
Image Processing and Connectivity
|
|
|
Image Processing |
ONYX® ThriveTM print workflow software Océ Edition |
|
Connectivity |
10 / 100 / 1000Base-T Ethernet |
Operational Environment and Dimensions
|
|
|
Electrical |
-
2 x 50Hz, 200 - 240VAC, single phase, 16A
-
2 x 60Hz, 200 - 240VAC, single phase, 20A
|
|
Operating Environment |
-
Temperature: 18°C to 30°C
-
RH: 30% - 70%, non-condensing
|
|
Physical |
-
Printer only: 4.66m x 3.83m; 1,615kg, uncrated
-
Printer + Roll Media Option: 4.66m x 4.12m; 1,865kg, uncrated
|
Other
|
|
|
Service & Support |
Canon offers several contract options tuned to individual customer needs, to ensure the highest printer uptime, enabling our customers to achieve their business goals. |
