| Technology |
|
| Printer Type |
5 Color - 36" |
| Number of Nozzles |
15,360 nozzles (5,120 nozzles for MBK, 2,560 nozzles for BK, C, M, Y)
1 print head |
| Print Resolution |
2400 x 1200dpi |
| Nozzle Pitch |
1200dpi x 2 rows |
| Line Accuracy |
±0.1% or less |
| Ink Droplet Size |
4 Picoliter |
| Ink Capacity |
130ml or 300ml per color |
| Ink Type |
Dye / Pigment Reactive Ink
Dye: C, M, Y, BK
Pigment: MBK |
| Ink Supply Method |
Tubing system
(supplies ink from independent ink tanks set in the printer through tubes) |
| OS Compatibility |
32-bit: Windows XP, Windows Vista, Windows 7 / 8 / 8.1, Windows Server 2003 / 2003R2 / 2008
64-bit: Windows Vista, Windows 7 / 8 / 8.1, Windows Server 2003 / 2003R2 / 2008 / 2008R2 / 2012 / 2012R2
Mac OSX: 10.6.8 - OS10.9.x |
| Printer Language |
GARO (Graphic Arts language with Raster Operations),
HP-GL/2, HP RTL |
Standard Interfaces
(Built-in) |
USB 2.0 Hi-Speed
Ethernet 10/100/1000 Base-T/TX |
| Printing Speed |
|
| Printing Speed |
A0 size, Plain Paper: |
46 sec (Draft Mode, 300dpi) |
| A0 size, Coated Paper: |
159 sec (Standard Mode, 600dpi) |
| A0 size, Glossy Photo Paper: |
252 sec (Standard Mode, 600dpi) |
| Memory |
|
| Standard Memory |
256MB (32GB RAM for iPF786 only) |
| Hard Disk |
320GB (for iPF786 only) |
| Media Handling |
|
| Media Width |
Roll Paper: |
254 - 914.4mm |
| Cut Sheet: |
203.2 - 917mm |
| Media Thickness |
Roll Paper: |
0.07 - 0.8mm |
| Cut Sheet: |
0.07 - 0.8mm |
| Minimum Printable Length |
Roll Paper: |
203.2mm |
| Cut Sheet: |
279.4mm |
| Maximum Printable Length |
Roll Paper: |
18m |
| Cut Sheet: |
1.6m |
| Maximum Media Roll Diameter |
150mm |
| Media Core Size |
Internal diameter of roll core: 2" or 3" |
| Paper Feed Method |
Roll Paper: |
One roll, Top Loading, Front Output |
| Cut Sheet: |
Top-feeding, Front Output (Manual Feed using media locking lever) |
Borderless Printing Width
(Roll Paper only) |
10" (254 mm), B4 (257 mm), A3 (297 mm), Banner (300 mm), 14" (356 mm), A2 (420 mm), A2+/17" (432 mm), B2 (515 mm), A1 (594 mm), 24" (610 mm), B1 (728 mm), A0 (841 mm), 36" (914 mm) |
| Dimensions and Weight |
|
Physical Dimensions
(W x D x H) |
Main unit with pallet: |
1,434 x 1,130 x 795mm;
Weight: approx. 113kg |
| Main unit with printer stand (excluding consumables): |
1,304 x 877 x 1,062mm;
Weight: approx. 67.9kg |
| Power and Operating Requirements |
|
| Power Supply |
AC 100 - 240V (50 - 60Hz) |
| Power Consumption |
Operation |
140W or less |
| Standby |
5W or less |
| Power off (Standby) |
0.5W or less |
| Operating Environment |
Temperature: |
15 - 300°C |
| Humidity: |
10 - 80% (Condensation-free) |
| Noise Level (Approx.) |
Operation |
48dB (A) or less |
| Standby |
35dB (A) or less |
| Accoustic Power |
6.5Bels or less |
| Environment Certifications |
Energy Star, RoHS directive, The ECO Declaration, WEEE |
