Printer Type |
6 Colour - 24" |
|
Number of Nozzles |
2,560 nozzles x 6 colours, 1 print head |
|
Print Resolution |
2400 x 1200dpi |
|
Nozzle Pitch |
1200dpi x 2 rows |
|
Line Accuracy |
±0.1% or less |
|
Ink Droplet Size |
4 Picoliter |
|
Ink Capacity |
130ml or 300ml per colour
Bundled Starter Ink: 90ml |
|
Ink Type |
Pigment ink - 6 colours
(BK / MBK / C / M / Y / R) |
|
Ink Supply Method |
Tubing system (with sub-ink tank) |
|
OS Compatibility |
Windows® (XP / Vista 32 / 64bit / Windows 7 32 / 64bit) Macintosh® (OSX) |
|
Printer Language |
GARO (Graphic Arts language with Raster Operations) |
Standard Interfaces
(Built-in) |
USB 2.0 Hi-Speed
Ethernet 10/100 Base-T/TX |
|
|
|
Printing Speed
(A1 size, Plain Paper) |
34sec. (Fast Economy Mode)
58sec. (Fast Mode)
105sec. (Standard Mode) |
Printing Speed
(A1 size, Coated Paper) |
60sec. (Fast Mode)
105sec. (Standard Mode) |
Printing Speed
(A1 size, Glossy Photo Paper) |
118sec. (Fast Mode)
221sec.(Standard Mode) |
|
|
|
|
Standard Memory |
256MB |
|
|
|
|
Media Width |
Roll Paper: |
203.2mm to 610mm |
|
Cut Sheet: |
203.2mm to 610mm (Top Loading, Manual Feed) |
|
Media Thickness |
Roll Paper: |
0.07mm to 0.8mm |
|
Cut Sheet: |
0.07mm to 0.8mm (Top Loading, Manual Feed) |
|
Minimum Printable Length |
Roll Paper: |
203.2mm |
|
Cut Sheet: |
279.4mm |
|
Maximum Printable Length |
Roll Paper: |
18m (varies according to the OS and application) |
|
Cut Sheet: |
1.6m |
|
Maximum Media Roll Diameter |
150mm |
|
Media Core Size |
Internal diameter of roll core: 2" or 3" |
|
Paper Feed Method |
Roll Paper: |
One Roll, Top Loading, Front Output |
|
Cut Sheet: |
Top Loading Manual Feed: One sheet, Front Output |
Borderless Printing Width
(Roll Paper only) |
10" (254mm), B4 (257mm), 14" (356mm), 16" (407mm), A2 (420mm), A2+/17" (432mm), B2 (515mm), A1 (594mm), 24" (610mm) |
|
|
|
Physical Dimensions
(W x D x H) |
1,017 (W) x 702 (D) x 344 (H) mm
Weight: approx. 44kg
(excluding consumables and a printer stand)
1,017 (W) x 870 (D) x 991 (H) mm
Weight: approx. 54kg
(Main unit with basket opened and a printer stand excluding consumables)
Basket closed: 1,017 (W) x 751 (D) x 991 (H) mm
1,180 (W) x 916 (D) x 645 (H) mm
Weight: approx. 74kg
(Main unit with pallet)
|
|
|
|
|
Power Supply |
AC 100 to 240V (50 to 60Hz) |
|
Power Consumption |
Operation: |
100W or less |
|
Standby: |
5W or less |
|
Power off (Standby) |
0.5W or less |
|
Operating Environment |
Temperature: |
15 to 30°C |
|
Humidity: |
10 to 80% (Condensation-free) |
|
Noise Level (Approx.) |
Operation: |
49dB (A) or less |
|
Standby: |
35dB (A) or less |
|
Accoustic Power: |
6.4 Bels or less |
|
Environment Certifications |
International Energy Star Program (WW), RoHS directive |
