| | LUCIA EX; 8-color ink: MBK, BK, C, M, Y, PC, PM, GY |
| | 2400 x 1200dpi |
| | Main unit with Auto Roll Feed Unit (standard) | 1,177 x 670 x 344mm;
Weight: approx. 51kg (excluding consumables and Printer Stand) |
| Main unit and Printer Stand | 1,177 x 870 x 991mm;
Weight: approx. 66kg (excluding consumables) |
| | Main unit (pallet included) | 1,320 x 914 x 645mm;
Weight: approx. 79kg |
| Printer Stand | 1,115 x 864 x 237mm;
Weight: approx. 22kg |
| | Input power | AC 100 - 240V (50 - 60Hz) |
| Power consumption | Operation: 100W or less |
Standby power consumption
(At the low power mode) | 100V - 120V: 6W or less
220V - 240V: 7W or less |
| Power off (standby) | 1W or less
(In compliance with Executive Order of the President of the United States of America) |
| | Temperature: 15 - 30°C, Humidity: 10 - 80 % (Condensation free) |
| | Acoustic pressure | Operation: 47dB (A), (Coated paper; Print Priority: Image; Standard mode)
Standby: 35dB (A) or less
(measured based on ISO7779 in the above conditions) |
| Acoustic power (LWAd) | Operation: approx 6.4 Bels, (Coated paper; Print Priority: Image; Standard mode) (measured based on ISO7779 in the above conditions) |
| | Standard memory | 384MB |
| | 2.5" 160GB 5400rpm S-ATA I/F |
| | Hi-Speed USB Type: | Built-in |
| Hi-Speed USB Mode | Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer |
| Hi-Speed USB Connector Type | Series B (4 pins) |
| Ethernet Type | Built-in |
| Ethernet Standard | IEEE 802.3 10base-T, IEEE 802.3u 100base-TX / Auto-Negotiation, IEEE 802.3ab 1000base-T / Auto-Negotiation, IEEE 802.3x Full Duplex |
| Ethernet Protocol | IPX/SPX (Netware 4.2(J), 5.1(J), 6.0(J)), SNMP (Canon-MIB), HTTP, TCP/IP (IPv4/IPv6), AppleTalk |
| | |
| Media Feed and Output | Roll paper (Auto Roll Feed Unit: Standard) | One Roll (Top-loading [Front Operation possible], Front Output) |
| Cut sheet | Manual Feed (1 sheet): Front-loading and Front Output, Top-loading and Front Output |
| Paper path switch (roll/cut sheet) | Manually switchable by user |
| Delivery direction | Face-up, Front side |
| Media Take-up Unit | - |
| Maximum stacking number of delivered prints | Basket: one sheet |
| Media Size | Roll paper (Width) | ISO - A3, A2, A1 JIS - B4, B2
ARCH - D (24")
Others - 8", 10", 14", 16", 17", 300mm, A3+ (329mm) |
| Cut sheet | Top-loading: ISO - A4, A3, A3+, A2, A2+, A1, B4, B3, B2
DIN - C4, C3, C2 JIS - B4, B3, B2
ANSI - 8.5 x 11", 8.5 x 14", 11 x 17", 13 x 19", 17 x 22", 22 x 34"
ARCH - 9 x 12", 12 x 18", 18 x 24", 24 x 36"
Photo - 20 x 24", 18 x 22", 14 x 17", 12 x 16", 10 x 12", 10 x 15", 16 x 20"
(US Photo size) Poster - 20 x 30", 300 x 900mm
Others - 13 x 22"
Front-loading: ISO - A2, A1, B2 DIN - C2 JIS - B2
ANSI - 17 x 22", 22 x 34"
ARCH - 18 x 24", 24 x 36"
Photo - 20 x 24", 18 x 22"
Poster - 20 x 30" Others - 13 x 22" |
| Media Thickness | Roll paper | 0.07 - 0.8mm |
| Cut sheet | Manual Feed (Top): 0.07 - 0.8mm
Manual Feed (Front): 0.5 - 1.5mm |
| Maximum Outside Diameter of Roll Paper | 150mm |
| Media Core Size | Internal diameter of roll core: 2" / 3" |
| Media Width | Roll paper | 203.2mm - 610mm |
| Cut sheet | Manual Feed (Top): 203.2mm - 610mm
Manual Feed (Front): 250 - 610mm (24"); POP board use only: A2, A1 |
| Minimum Printable Paper Length | Roll paper | 203.2mm |
| Cut sheet | Manual Feed (Top): 279.4mm
Manual Feed (Front): 350mm |
| Maximum Printable Paper Length | Roll paper | 18m (Varies according to the OS and application) |
| Cut sheet | Manual Feed (Top): 1.6mm
Manual Feed (Front): 914mm |
| Margins | Recommended area (Roll paper) | Left: 5mm, Right: 5mm, Top: 20mm, Bottom: 5mm |
| Recommended area (Cut sheet) | Manual Feed (Top): Left: 5mm, Right: 5mm, Top: 20mm, Bottom: 23mm |
| Manual Feed (Front): Left: 5mm, Right: mm, Top: 20mm, Bottom: 23mm |
| Printable area (Roll paper) | Left: 3 mm, Right: 3mm, Top: 3mm, Bottom: 3mm
Borderless print: Left: 0mm, Right: 0mm, Top: 0mm, Bottom: 0mm |
| Printable area (Cut sheet) | Manual Feed (Top): Left: 3mm, Right: 3mm, Top: 3mm, Bottom: 3mm (*1)
*1: Bottom 23 mm for art paper
Manual Feed (Front): Left: 3mm, Right: 3mm, Top: 3mm, Bottom: 23mm |
| Borderless Printing (Roll paper only) | Media width | 10" (254mm), B4 (257mm), A3+ (329mm), 14" (356mm), 16" (407mm), A2 (420mm), A2+/17" (432mm), B2 (515mm), A1 (594mm), 24" (610mm) |
| Media feed capacity | Manual feed | 1 sheet (from top, from front) |
