PF-05 |
|
FINE (Photolithography Inkjet Nozzle Engineering) |
|
2400 x 1200dpi |
|
2,560 Nozzles per Colour (30,720 Total) |
|
4 Picoliter |
|
1200dpi x Two Rows |
|
|
| Ink Type |
LUCIA EX (pigment-based) |
| Model |
PFI-105 (BK, MBK, C, M, Y, PC, PM, GY, PGY, R, G, B) |
| Ink Capacity |
130ml each (bundled starter ink: 90ml) |
| Number of Colours |
12 |
| Ink Supply Method |
Tubing system (with sub-tank) |
| Nozzle Recovery System |
Non-firing Nozzle Detection and Compensation |
| Printer Controller |
L-COA Controller |
| Printer Memory |
384MB |
| Media feed |
Top-loading (Front operation possible) Roll Paper, Front-loading Manual Feed,
Top-loading Manual Feed |
| Hard Disk |
80GB (iPF6350 only) |
|
203.2mm - 610mm |
|
|
| Cutsheet |
Manual feed from the top: |
ISO A4, A3, A3+, A2, A2+, A1, B4, B3, B2 DIN C4, C3, C2 JIS B4, B3, B2 ANSI 8.5 x 11", 8.5 x 14", 11 x 17", 13 x 19", 17 x 22", 22 x 34" ARCH 9 x 12", 12 x 18", 18 x 24", 24 x 36" Photo 20 x 24", 18 x 22", 14 x 17", 12 x 16", 10 x 12", 10 x 15", 16 x 20" (US Photo size) Poster 20 x 30", 300 x 900mm Others 13 x 22" |
| Manual feed from the front: |
ISO A2, A1, B2 DIN C2 JIS B2 ANSI 17 x 22", 22 x 34" ARCH 18 x 24", 24 x 36" Photo 20 x 24", 18 x 22" Poster 20 x 30" Others 13 x 22" |
| Roll paper |
Width: |
ISO A3, A2, A1 JIS B4, B2 ARCH D (24") Others 8", 10", 14", 16", 17", 300mm, A3+ (329mm) |
| Media Type*1 |
Plain Paper, Plain paper (High Quality), Recycled coated paper, Coated paper, Heavyweight coated paper, Extra heavyweight coated paper, Premium matte paper, Glossy photo paper, Semi-glossy photo paper, Heavyweight glossy photo paper, Heavyweight semi-glossy photo paper, Poster semi-glossy phot paper, Satin Photographic paper 190gsm, Synthetic paper, Adhesive Synthetic paper, Backlit film, Backprint film, Flame-Resistant cloth, Thin fabric Banner, Proofing paper, Fine art photo, Fine art heavyweight photo, Fine art textured, Fine art watercolour, Fine art block print, Canvas matte, Japanese paper washi, Coloured coated paper, CAD Tracing paper, CAD Translucent matte film, POP board and others |
|
|
| Roll Feed |
All Sides: |
3mm or 0mm for Borderless |
| Manual Feed |
Left, Right, Top: |
3mm |
| Bottom: |
23mm (Front feed) or 3mm (Top feed) |
|
|
| Roll Feed |
8.0" (203.2mm) |
| Top-loading Manual Feed |
11.0" (279.4mm) |
| Front-loading Manual Feed |
13.78" (350mm) |
|
|
| Roll Feed |
59" (18m) |
| Top-loading Manual Feed |
5.2" (1.6m) |
| Front-loading Manual Feed |
36.0" (914mm) |
| Borderless Printing Widths (Roll Media Only) |
10" (254mm), B4 (257mm), 14" (356mm), 16" (407mm), A2 (420mm), A2+ / 17" (432mm), B2 (515mm), A1 (594mm), 24" (610mm) |
| Media Cutter |
Automatic horizontal cutting (Rotary cutter), independent unit |
|
|
| Roll Feed |
0.07 - 0.8mm |
| Top-loading Manual Feed |
0.07 - 0.8mm |
| Front-loading Manual Feed |
0.5 - 1.5mm |
| Media Core Sizes |
Internal diameter of roll core: |
2" / 3" |
| Maximum Roll Outer Diameter |
150mm |
|
|
| Printing Software |
imagePROGRAF Printer Driver, Print Plug-in for Photoshop, Print Plug-in for DPP, Printer Driver Extra Kit (Free Layout, imageRUNNER Linking Function), Print Plug-in for Microsoft Office |
| Utilities |
Media Configuration Tool, GARO Status Monitor (Windows) /
Print Monitor (MAC), Remote UI |
| Applications |
Digital Photo Front-Access, Poster Artist 2009 (optional) |
|
GARO (Canon Proprietary) |
|
Windows (2000, XP, Server 2003, 2008, Vista, Windows 7) 32 / 64 bit
Macintosh (OSX 10.3.9 and above) 32 / 64 bit |
|
|
| Standard (Built-in) |
USB 2.0 Hi-Speed, 10 / 100 / 1000base-TX |
| Optional |
IEEE1394 (FireWire) |
|
|
| Operation |
Approx. 47dB (A) or Less |
| Standby |
35dB (A) or Less |
| Acoustic Power |
6.4 Bels or Less |
|
AC 100 - 240V (50 - 60Hz) |
|
|
| Maximum |
100W or Less |
| Standby (100 - 120V) |
6W or Less |
| Standby (220 - 240V) |
7W or Less |
| Power Off |
1W or Less (Executive Order Compliant) |
|
ENERGY STAR (WW), RoHS directive, IT ECO Declaration(Europe), WEEE, Executive Order of the President of the United States of America, China RoHS |
|
|
| Temperature |
15 - 30°C |
| Relative Humidity |
10 - 80% (No Condensation) |
|
1177 x 870 x 991mm (with Printer Stand) |
|
Approx. 66kg |
|
Print Head (PF-05)
Ink Tanks (PFI-105)
Maintenance Cartridge (MC -16) |
