| Printing Method |
Thermal Transfer Method |
| Resolution |
300 dpi |
| Printing Speed |
Tube:
High speed mode: 25 mm/sec
Standard speed mode: 18.5 mm/sec
Low speed mode: 12.5 mm/sec
Label:
High speed mode: 25 mm/sec
Standard/Low speed mode: 18.5 mm/sec |
| Processing Speed |
High speed mode: about 35 pieces/min
Standard speed mode: about 30 pieces/min
Low speed mode: about 21 pieces/min
Conditions for printing and cutting – tube cut length: 20 mm, number of characters: 5 (two-byte characters of 3 mm wide), half cutting: on, cut strength: standard |
| Ink Ribbon |
Ribbon IC cassette (black, white)
Length – black: 40 m, 100 m, white: 85 m |
| Size of Characters |
2 mm (Kanji characters not supported for this size), 3 mm, 6 mm (both one-byte and two-byte characters suppoted) |
| Types of Characters |
JIS First-Level Kanji, JIS Second-Level Kanji, symbols |
| Data Entering |
Rubber keyboard
Roman character conversion input*1, Hiragana input,
alphanumeric input, area code input, symbol input |
| Vocabulary of Dictionary |
About 5,000 words |
| Display |
| Number of Characters Displayed |
Input data: 10 characters × 2 lines (two-byte characters),
or 20 characters x 2 lines (one-byte characters) |
| Memory Capacity |
Storage for character data: about 2,500 characters*2
Storage for files: about 7,500 characters*2
Folder hierarchy: none |
| Cutting Method |
Automatic half cut, automatic full cut |
| Power |
AC adapter (100 VAC – 240 VAC, 50/60 Hz) |
| Interface |
– |
| Operating Environment |
Temperature: 15°C to 32.5°C, Humidity: 10% to 85%
The tube warmer (optional) allows for the use of this product even at low temperatures of 5°C to 18°C. |
| Maximum Power Consumption |
12.5 W |
| Storage Environment |
Temperature: 5°C to 35°C, Humidity: 10% to 90% |
| Main Body Dimensions |
Width: 250 mm x Depth: 300 mm x Height: 85 mm |
| Main Body Weight |
2 kg |
| Media Types |
Tube |
Commercially available PVC round tube*3
(Inner diameter: 2.5 mm to 5.2 mm, thickness: 0.5 mm) |
| Label Tape |
Cassette (white, yellow, silver) – width: 6 mm, 9 mm, 12 mm, length: 30 m (27 m for silver)
Adjustable range of cut length: 8 mm to 150 mm*4 |
| Wrap Around Tape |
Cassette (white in the areas to be printed, transparent in other areas)
Winding length: 8 m, length: 33 mm, width: 8 mm to 150 mm (adjustable by the cut length setting) |
| Marking Strip |
– |
| 4-mm ID Strip |
Cassette (white) – width: 4 mm, length: 5 m
Adjustable range of cut length: 8 mm to 150 mm |
