Printer

Printer Type 5-Colour 44″ (1,118 mm)
Number of Nozzles 15,360 nozzles (MBK: 5,120 nozzles; BK, C, M, Y: 2,560 nozzles each)
Maximum Print Resolution 2400 × 1200 dpi
Nozzle Pitch 1200 dpi (2 lines)
Line Accuracy*1 ± 0.1% or less
Minimum Ink Droplet Size 5 pl
Ink Capacity Sales Ink: 160 ml / 330 ml / 700 ml (MBK, BK, C, M, Y)
Bundled Starter Ink: 330 ml (MBK) / 160 ml (BK, C, M, Y)
Ink Type Pigment Ink
Printer Language SG Raster (Swift Graphic Raster)
HP-GL/2
HP RTL
PDF (Ver. 1.7)
JPEG (Ver. JFIF1.02)
Printing Solutions Apple AirPrint, Direct Print Plus, Direct Print & Share, CPP Driver Select & Publisher Select, AutoCAD Optimized Printer Driver, Easy-PhotoPrint Editor, Canon PRINT Inkjet/SELPHY, Canon Print Service, Free Layout plus, PosterArtist Lite, imageRUNNER ADVANCE Direct Enlargement Copy
Management Solutions Media Configuration Tool, Accounting Manager, Device Management Console, Quick Utility Box
Standard Interfaces (Built-in) USB A Port:
USB Memory (Direct Print)

USB B Port (Series B, 4 pins):
Hi-Speed USB
Full Speed (12 Mbit/sec)
High Speed (480 Mbit/sec)
Bulk Transfer

Gigabit Ethernet:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX/Auto-Negotiation
IEEE 802.3ab 1000base-T/Auto-Negotiation
IEEE 802.3x Full Duplex
SNMP, HTTP, FTP, TCP/IP (IPv4/IPv6)

Wireless LAN:
IEEE802.11 b/g/n
WEP (64/128bit)
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Memory Standard: 128 GB
Physical: 2 GB
Hard Disk 500 GB (Encrypted)

Print Speed*2

Plain Paper
CAD Drawings, A0 34 sec [Fast (Custom Q5)]
37 sec [Fast]
1 min 4 sec [Standard]
Poster, A0 37 sec [Fast (Custom Q5)]
42 sec [Fast]
1 min 15 sec [Standard]
Heavyweight Coated Paper HG
Poster, A0 1 min 38 sec [Fast]
2 min 33 sec [Standard]
Glossy Photo Paper HG 170
Poster, A0 2 min 59 sec [Fast]
5 min 44 sec [Standard]

Media Handling

Media Feed and Output
Roll Paper (Single) Front Load, Front Output
Cut Sheet Front Load, Front Output*3
Media Width (Roll / Cut Sheet) 152.4 ~ 1,118 mm
Media Thickness (Roll / Cut Sheet) 0.07 ~ 0.8 mm
Min. Printable Length
Roll Paper 101.6 mm*4
Cut Sheet 203.2 mm
Max. Printable Length
Roll Paper 18 m*5
Cut Sheet 1.6 m
Maximum Outer Roll Diameter 170 mm or less
Borderless Printing Width
(Roll paper only)
152.4 ~ 1,118 mm
Margins (Recommended Area)
Roll Paper Top: 20 mm, Bottom: 3 mm, Side: 3 mm
Cut Sheet (Apple AirPrint) Top: 20 mm, Bottom: 31 mm, Side: 3 mm
Cut Sheet (Others) Top: 20 mm, Bottom: 20 mm, Side: 3 mm
Margins (Printable Area)
Roll Paper Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll Paper (Borderless Print) Top: 0 mm, Bottom: 0 mm, Side: 0 mm
Cut Sheet (Apple AirPrint) Top: 3 mm, Bottom: 12.7 mm, Side: 3 mm
Cut Sheet (Others) Top: 3 mm, Bottom: 20 mm, Side: 3 mm

Dimensions & Weight*6

Dimensions (W x D x H)
Main Unit + Stand + Basket 1593 x 984 x 1168 mm (Basket Open)
1593 x 766 x 1168 mm (Basket Closed)
Main Unit + Roll Unit + Stand + Stacker 1593 x 1188 x 1168 mm (Basket Open)
1593 x 1122 x 1168 mm (Basket Closed)
Roll Unit 1577 x 336 x 318 mm
Weight
Main Unit + Stand + Basket 114 kg
Main Unit + Roll Unit + Stand + Stacker 146 kg
Roll Unit 20 kg
Packaged Dimensions (W x D x H)
Main Unit + Stand + Basket + Pallet 1820 x 915 x 1061 mm
Stacker 1464 x 906 x 291 mm
Roll Unit 1727 x 562 x 461 mm
Packaged Weight
Main Unit + Stand + Basket + Pallet 165 kg
Stacker 25 kg
Roll Unit 30 kg

Power & Operating Requirements

Power Supply AC 100 – 240 V, 50 – 60 Hz
Power Consumption
Printing 116 W or less
Sleep Mode 2.0 W or less
Power Off 0.3 W or less
Operating Environment
Temperature 15 ~ 30 ℃
Humidity 10 ~ 80 % RH (no dew condensation)
Acoustic Sound
Acoustic Power*7 Operation: Approx. 69 dB
Acoustic Pressure*7 Operation: Approx. 51 dB (A)
Standby: 35 dB (A) or less

Accessories

Roll Unit (Required) RU-42
Stacker (Optional) SS-41
2″/3″ Roll Holder (Optional) RH2-46

Consumables

Print Head PF-06
Cutter Blade CT-07
Maintenance Cartridge MC-30
Ink Tank PFI-8110 (160 ml) / PFI-8310 (330 ml) / PFI-8710 (700 ml)
Matte Black / Black / Cyan / Magenta / Yellow
  1. User adjustments is required.
    Printing environment and media must match those used for the adjustments.
    Paper required: Plain paper, CAD tracing paper, coated paper, CAD translucent matte film only.
  2. Time taken to print one page, does not include time required for data processing, data transfer and pre-printing operations.
  3. Manual feed using media locking lever.
  4. For cloth, canvas, tracing paper and translucent matte film media, minimum printable length is 200 mm.
  5. Varies according to the OS and application.
  6. Include roll holder set, exclude ink and print head.
  7. Measured using ISO 7779 standard by using 36 inch plain paper, standard mode and line drawing / text mode.

Chi tiết

ẨnHiện

Printer

Printer Type

5-Colour 44" (1,118 mm)

Number of Nozzles

15,360 nozzles (MBK: 5,120 nozzles; BK, C, M, Y: 2,560 nozzles each)

Maximum Print Resolution

2400 × 1200 dpi

Nozzle Pitch

1200 dpi (2 lines)

Line Accuracy*1

± 0.1% or less

Minimum Ink Droplet Size

5 pl

Ink Capacity

Sales Ink: 160 ml / 330 ml / 700 ml (MBK, BK, C, M, Y)
Bundled Starter Ink: 330 ml (MBK) / 160 ml (BK, C, M, Y)

Ink Type

Pigment Ink

Printer Language

SG Raster (Swift Graphic Raster)
HP-GL/2
HP RTL
PDF (Ver. 1.7)
JPEG (Ver. JFIF1.02)

Printing Solutions

Apple AirPrint, Direct Print Plus, Direct Print & Share, CPP Driver Select & Publisher Select, AutoCAD Optimized Printer Driver, Easy-PhotoPrint Editor, Canon PRINT Inkjet/SELPHY, Canon Print Service, Free Layout plus, PosterArtist Lite, imageRUNNER ADVANCE Direct Enlargement Copy

Management Solutions

Media Configuration Tool, Accounting Manager, Device Management Console, Quick Utility Box

Standard Interfaces (Built-in)

USB A Port:
USB Memory (Direct Print)

USB B Port (Series B, 4 pins):
Hi-Speed USB
Full Speed (12 Mbit/sec)
High Speed (480 Mbit/sec)
Bulk Transfer

Gigabit Ethernet:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX/Auto-Negotiation
IEEE 802.3ab 1000base-T/Auto-Negotiation
IEEE 802.3x Full Duplex
SNMP, HTTP, FTP, TCP/IP (IPv4/IPv6)

Wireless LAN:
IEEE802.11 b/g/n
WEP (64/128bit)
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Memory

Standard: 128 GB
Physical: 2 GB

Hard Disk

500 GB (Encrypted)

Print Speed*2

Plain Paper

CAD Drawings, A0

34 sec [Fast (Custom Q5)]
37 sec [Fast]
1 min 4 sec [Standard]

Poster, A0

37 sec [Fast (Custom Q5)]
42 sec [Fast]
1 min 15 sec [Standard]

Heavyweight Coated Paper HG

Poster, A0

1 min 38 sec [Fast]
2 min 33 sec [Standard]

Glossy Photo Paper HG 170

Poster, A0

2 min 59 sec [Fast]
5 min 44 sec [Standard]

Media Handling

Media Feed and Output

Roll Paper (Single)

Front Load, Front Output

Cut Sheet

Front Load, Front Output*3

Media Width (Roll / Cut Sheet)

152.4 ~ 1,118 mm

Media Thickness (Roll / Cut Sheet)

0.07 ~ 0.8 mm

Min. Printable Length

Roll Paper

101.6 mm*4

Cut Sheet

203.2 mm

Max. Printable Length

Roll Paper

18 m*5

Cut Sheet

1.6 m

Maximum Outer Roll Diameter

170 mm or less

Borderless Printing Width
(Roll paper only)

152.4 ~ 1,118 mm

Margins (Recommended Area)

Roll Paper

Top: 20 mm, Bottom: 3 mm, Side: 3 mm

Cut Sheet (Apple AirPrint)

Top: 20 mm, Bottom: 31 mm, Side: 3 mm

Cut Sheet (Others)

Top: 20 mm, Bottom: 20 mm, Side: 3 mm

Margins (Printable Area)

Roll Paper

Top: 3 mm, Bottom: 3 mm, Side: 3 mm

Roll Paper (Borderless Print)

Top: 0 mm, Bottom: 0 mm, Side: 0 mm

Cut Sheet (Apple AirPrint)

Top: 3 mm, Bottom: 12.7 mm, Side: 3 mm

Cut Sheet (Others)

Top: 3 mm, Bottom: 20 mm, Side: 3 mm

Dimensions & Weight*6

Dimensions (W x D x H)

Main Unit + Stand + Basket

1593 x 984 x 1168 mm (Basket Open)
1593 x 766 x 1168 mm (Basket Closed)

Main Unit + Roll Unit + Stand + Stacker

1593 x 1188 x 1168 mm (Basket Open)
1593 x 1122 x 1168 mm (Basket Closed)

Roll Unit

1577 x 336 x 318 mm

Weight

Main Unit + Stand + Basket

114 kg

Main Unit + Roll Unit + Stand + Stacker

146 kg

Roll Unit

20 kg

Packaged Dimensions (W x D x H)

Main Unit + Stand + Basket + Pallet

1820 x 915 x 1061 mm

Stacker

1464 x 906 x 291 mm

Roll Unit

1727 x 562 x 461 mm

Packaged Weight

Main Unit + Stand + Basket + Pallet

165 kg

Stacker

25 kg

Roll Unit

30 kg

Power & Operating Requirements

Power Supply

AC 100 - 240 V, 50 - 60 Hz

Power Consumption

Printing

116 W or less

Sleep Mode

2.0 W or less

Power Off

0.3 W or less

Operating Environment

Temperature

15 ~ 30 ℃

Humidity

10 ~ 80 % RH (no dew condensation)

Acoustic Sound

Acoustic Power*7

Operation: Approx. 69 dB

Acoustic Pressure*7

Operation: Approx. 51 dB (A)
Standby: 35 dB (A) or less

Accessories

Roll Unit (Required)

RU-42

Stacker (Optional)

SS-41

2"/3" Roll Holder (Optional)

RH2-46

Consumables

Print Head

PF-06

Cutter Blade

CT-07

Maintenance Cartridge

MC-30

Ink Tank

PFI-8110 (160 ml) / PFI-8310 (330 ml) / PFI-8710 (700 ml)
Matte Black / Black / Cyan / Magenta / Yellow


  1. User adjustments is required.
    Printing environment and media must match those used for the adjustments.
    Paper required: Plain paper, CAD tracing paper, coated paper, CAD translucent matte film only.
  2. Time taken to print one page, does not include time required for data processing, data transfer and pre-printing operations.
  3. Manual feed using media locking lever.
  4. For cloth, canvas, tracing paper and translucent matte film media, minimum printable length is 200 mm.
  5. Varies according to the OS and application.
  6. Include roll holder set, exclude ink and print head.
  7. Measured using ISO 7779 standard by using 36 inch plain paper, standard mode and line drawing / text mode.
