Technology |
|
|
Printer Type |
5 Color - 24" |
|
Number of Nozzles |
15,360 nozzles (5,120 nozzles for MBK, 2,560 nozzles for BK, C, M, Y)
1 print head |
|
Print Resolution |
2400 x 1200dpi |
|
Nozzle Pitch |
1200dpi x 2 rows |
|
Line Accuracy |
±0.1% or less |
|
Ink Droplet Size |
4 Picoliter |
|
Ink Capacity |
130ml or 300ml per color |
|
Ink Type |
Dye / Pigment Reactive Ink
Dye: C, M, Y, BK
Pigment: MBK |
|
Ink Supply Method |
Tubing system
(supplies ink from independent ink tanks set in the printer through tubes) |
|
OS Compatibility |
32-bit: Windows XP, Windows Vista, Windows 7 / 8 / 8.1, Windows Server 2003 / 2003R2 / 2008
64-bit: Windows Vista, Windows 7 / 8 / 8.1, Windows Server 2003 / 2003R2 / 2008 / 2008R2 / 2012 / 2012R2
Mac OSX: 10.6.8 - OS10.9.x |
|
Printer Language |
GARO (Graphic Arts language with Raster Operations),
HP-GL/2, HP RTL |
Standard Interfaces
(Built-in) |
USB 2.0 Hi-Speed
Ethernet 10/100/1000 Base-T/TX |
|
Printing Speed |
|
|
Printing Speed |
A1 size, Plain Paper |
26 sec (Draft Mode, 300dpi) |
|
A1 size, Coated Paper |
88 sec (Standard Mode, 600dpi) |
|
A1 size, Glossy Photo Paper |
141 sec (Standard Mode, 600dpi) |
|
Memory |
|
|
Standard Memory |
256MB |
|
Hard Disk |
--- |
|
Media Handling |
|
|
Media Width |
Roll Paper: |
254 - 609.6mm |
|
Cut Sheet: |
203.2 - 609.6mm |
|
Media Thickness |
Roll Paper: |
0.07 - 0.8mm |
|
Cut Sheet: |
0.07 - 0.8mm |
|
Minimum Printable Length |
Roll Paper: |
203.2mm |
|
Cut Sheet: |
279.4mm |
|
Maximum Printable Length |
Roll Paper: |
18m |
|
Cut Sheet: |
1.6m |
|
Maximum Media Roll Diameter |
150mm |
|
Media Core Size |
Internal diameter of roll core: 2" or 3" |
|
Paper Feed Method |
Roll Paper: |
One roll, Top Loading, Front Output |
|
Cut Sheet: |
Top-feeding, Front Output (Manual Feed using media locking lever) |
Borderless Printing Width
(Roll Paper only) |
10" (254 mm), B4 (257 mm), A3 (297 mm), Banner (300 mm), 14" (356 mm), A2 (420 mm), A2+/17" (432 mm), B2 (515 mm), A1 (594 mm), 24" (610 mm) |
|
Dimensions and Weight |
|
Physical Dimensions
(W x D x H) |
Main unit with basket open, excluding consumables and a printer stand:
|
997 x 757 x 507mm;
Weight: approx. 46.0kg |
|
Main unit with printer stand and basket open excluding consumables: |
997 x 887 x 1,062mm;
Weight: approx. 56.7kg |
|
Main unit with pallet: |
1,127 x 878 x 795mm ;
Weight: approx. 74.0kg |
|
Power and Operating Requirements |
|
|
Power Supply |
AC 100 - 240V (50 - 60Hz) |
|
Power Consumption |
Operation:
|
140W or less |
|
Standby: |
5W or less |
|
Power off (Standby): |
0.5W or less |
|
Operating Environment |
Temperature: |
15 - 300°C |
|
Humidity: |
10 - 80% (Condensation-free) |
|
Noise Level (Approx.) |
Operation:
|
47dB (A) or less |
|
Standby: |
35dB (A) or less |
|
Accoustic Power: |
6.4Bels or less |
|
Environment Certifications |
Energy Star, RoHS directive, The ECO Declaration, WEEE |
