Image Sensor |
1/3 type CMOS (primary color filter) |
|
Number of Effective Pixels |
2.1 million pixels |
|
Scanning Method |
Progressive |
|
Lens |
30x optical zoom (20x digital zoom) lens with auto focus |
|
Focal Length |
4.4 (W) - 132mm (T) [W: Maximum Wide Angle, T:Maximum Telephoto] |
|
F-number |
F1.4 (W) - F4.6 (T) |
|
Viewing Angle |
For 16:9 aspect ratios |
Horizontal: 62.6 (W) - 2.2° (T) Vertical: 36.9 (W) - 1.3° (T) |
|
For 4:3 aspect ratios |
Horizontal: 48.5 (W) - 1.7° (T) Vertical: 36.9 (W) - 1.3° (T) |
|
Min. Subject Illumination |
Day Mode (color): |
0.05lux (F1.4, shutter speed 1/30 sec., when smart shade control is off, 50IRE) |
|
Night Mode (B&W): |
0.002lux (F1.4, shutter speed 1/30sec., when smart shade control is off, 50IRE) |
|
Focus |
Auto / One-shot AF / Manual / Fixed at infinity |
|
Shooting Distance (from front of lens) |
Day Mode: |
0.3m (12in.) - infinity (W), 2.0m (6.6ft.) - infinity (T) |
|
Night Mode: |
1.0m (3.3ft.) - infinity (W), 2.0m (6.6ft.) - infinity (T) |
|
Shutter Speed |
1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000, 1/16000sec. |
|
Exposure |
Auto / Auto (Flickerless) / Auto (Shutter-priority AE) / Auto (Aperture-priority AE) / Manual (Shutter Speed, Aperture, Gain) |
|
White Balance |
Auto / Light Source / Manual
Light Source: Daylight Fluorescent / White Fluorescent / Warm Fluorescent / Mercury Lamp / Sodium Lamp / Halogen Lamp, Manual: One-shot WB / R Gain / B Gain |
|
Metering Mode |
Center-Weighted / Average / Spot |
|
Haze Compensation |
Auto / Manual / Disable, Auto: 3 levels, Manual: 7 levels |
|
Pan Angle Range |
360°continuous panning |
|
Tilt Angle Range |
180° (ceiling-mounted position: 0 - 180°) [When the horizontal direction of the camera is 0°] |
|
Moving Speed |
Pan: Max. 450°/sec. Tilt: Max. 450°/sec. |
|
Frame Rate |
JPEG: 0.1 - 30fps , H.264: 1 / 2 / 3 / 5 / 6 / 10 / 15 / 30fps
- Values represent streaming performance from the camera. The frame rate may be reduced due to Viewer computer's specs, the number of clients accessing at the same time, network loads, video quality setting, type or movement of the subject or other reasons. Maximum frame rate when used in the following combinations:
When streaming H.264(1) (1920 x 1080) and H.264(2) (all sizes) simultaneously: 15fps ; When streaming H.264(1) (all sizes) and H.264(2) (1920 x 1080) simultaneously: 15fps
When streaming H.264(1) (1280 x 960) and H.264(2) (1280 x 960) simultaneously: 15fps ; When streaming H.264(1) (1280 x 720) and H.264(2) (1280 x 720) simultaneously: 15fps |
|
Simultaneous Client Access |
Max. 30 Clients + 1 Admin Client - H.264: Max. 10 Clients |
|
Bit Rate Control |
Target Bit Rate: 64 / 128 / 256 / 384 / 512 / 768 / 1024 / 2048 / 3072 / 4096 / 6144 / 8192 / 10240 / 12288 / 14336 / 16384kbps |
|
ADSR: Area-specific Data Size Reduction |
Number of Specified Areas: Max. 8 areas. Data Size Reduction Level: 3 levels |
|
Security |
Camera Control: Administrator, Authorized user, Guest user (level of control varies depending on user)
Access Control: User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
IEEE 802.1X: EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
Encrypted Communications: SSL / TLS, IPsec |
|
Protocol |
IPv4: TCP / IP, UDP, HTTP, FTP, SNMP (MIB2), SMTP (Client), DHCP (Client), DNS (Client), mDNS, ARP, ICMP, POP3 (Client), NTP (Client), SMTP authentication (POP before SMTP, SMTP-AUTH), AutoIP, RTP / RTCP, RTSP, SSL / TLS, IPsec, WV-HTTP (Canon proprietary), ONVIF (Profile S, Profile G)
IPv6: TCP / IP, UDP, HTTP, FTP, SMTP (Client), DHCPv6 (Client), DNS (Client), mDNS, ICMPv6, POP3 (Client), NTP (Client), SMTP authentication (POP before SMTP, SMTP-AUTH), RTP / RTCP, RTSP, SSL / TLS, IPsec, WV-HTTP (Canon proprietary), ONVIF (Profile S, Profile G) |
|
Audio Compression Method |
G.711 μ-law (64kbps) |
|
Audio Communication Method |
Full-duplex (two-way) - Echo cancellation function compliant
RTP, Sound Transfer Protocol by Canon |
|
Audio File Playback |
Available (audio files can be played back when an event is triggered by the intelligent function or external device input)
- A third-party amplifier speaker is necessary |
|
Preset |
Number of registers: Max. 256 positions (+Home Position). Number of Preset Tour Route: Max. 5 |
|
Intelligent Function (Video) |
Moving Object Detection, Abandoned Object Detection, Removed Object Detection, Camera Tampering Detection, Passing Detection, Intrusion Detection, and Auto Tracking.
Detection Settings: Max. 15. Non-detection Area Settings: Available |
|
Intelligent Function (Audio) |
Volume Detection, Scream Detection |
|
Event Trigger Type |
External Device Input, Intelligent Function (Video), Intelligent Function (Audio), Timer, Day / Night Switch
Number of Linked Events: 2, Linked Event Conditions: AND, OR (whether or not there is a sequence to events) |
|
Image Upload |
FTP / HTTP / SMTP (e-mail) |
|
Event Notification |
HTTP / SMTP (e-mail) |
|
Viewer |
Camera Viewer, Mobile Camera Viewer |
|
Admin Tools |
Privacy Mask Setting Tool, Panorama Creation Tool, View Restriction Setting Tool, Intelligent Function Setting Tool, Log Viewer, Recorded Video Utility |
|
Included Software |
Camera Management Tool, RM-Lite, Recorded Video Utility |
|
Network Terminal |
LAN x 1 (RJ45, 100Base-TX (auto / full-duplex / half-duplex)) |
Audio Input Terminal
(common for LINE IN & MIC IN) |
φ3.5mm (φ0.14in.) mini-jack connector (monaural), LINE IN (connect to an amplifier microphone) or
MIC IN (connect to a microphone w/o amplifier) - Switch LINE IN / MIC IN in the setting page. |
|
Audio Output Terminal (LINE OUT) |
φ3.5mm (φ0.14in.) mini-jack connector (monaural), LINE OUT (connect to an amplifier speaker) |
|
External Device I/O Terminal |
Input x 2, Output x 2 |
|
Memory Card |
SD Memory Card, SDHC Memory Card, SDXC Memory Card Compatible. Recorded Content: Log, Video (Event, Manual, ONVIF, Timer, Upload). Frame Rate: Max. 1fps (JPEG), Max. 30fps (H.264) - to insure reliability in the recording speed, it is recommended to use CLASS 10 rated products. Even when using CLASS 10 products, reliability cannot be guaranteed during heavy access loads (e.g., when recording and deleting data at the same time). |
|
Operating Environment |
Temperature
AC, DC, PoE: -10 - +50°C (+14 - +122°F)
Humidity
5 - 85% (without condensation) |
|
Storage Environment |
Temperature: -30 - +60°C (-22 - +140°F), Humidity: 5 - 90% (without condensation) |
|
Power Supply |
PoE: PoE power supply via LAN connector (IEEE 802.3 at Type1 compliant). AC Adapter: PA-V18 (100 - 240V AC) (sold separately). External power source: 24V AC / 12V DC |
|
Power Consumption |
PoE: Max. approx. 10.7W*, AC Adapter PA-V18: Max. approx. 11.3W (100V AC), Max. approx. 11.1W (240V AC). DC: Max. approx. 9.7W, AC: Max. approx. 10.2W |
|
Dimensions (camera only) |
(φ x H) φ199 x 199mm (φ7.83 x 7.83in.) |
|
Weight |
Approx. 1990g (4.39lb.) |
|
Impact Resistance |
- |
|
Dust-resistant/Waterproof Specification |
- |
